IO-LINK is a worldwide standardised IO technology (IEC 61131-9) for communicating with sensors and actuators. IO-LINK is a point-to-point communication system with 3-condtctor or 5-conductor connection technology for sensors and actuators and unshielded standard sensor lines.
IO-LINK devices are connected with standard commercial IO-LINK masters and can easily be integrated into all commonly used fieldbus and automation systems. 3-pin or 5-pin unshielded standard cables 20m in length between the IO-LINK device and IO-LINK master, are sufficient for connecting IO-LINK devices with IO-LINK masters
Technical Features
Sine pump convey mediums gently to ensure medium’s quality
Almost zero pulse
Outstanding intet suction capacity: -0.85bar (vacuum) / -12.3psi
Max flow: 93.6m³/h
Max Particles: 50mm
Max pressure: 15 bar
Max speed range: 900 R.P.M
Max working temperature: 100 ° C
Inner surface treatment: Ra≤0.6μm; EP Ra≤0.4μm
Material: 100% stainless steel, medium contact part 316L.
Multi functional high frequency canned diaphragm valve has a dual-station cylinder and a flow-adjustable filling valve.
For fast filling and to prevent spillage or spillage of the bottle.
The flow rate is maximum when 1 cylinder is working;
When the cylinder is working, the flow rate is the smallest, and the flow rate adjustment device can also be used to adjust the flow rate when the flow 2# cylinder is working.
●SIZE: 1/4 "-3/4", DN6-DN15
●Standard BPE 3A DIN ISO IDF
● Certification PED/97/23/EC, 3A/54-04/1580, FDA.177.2600
●Maximum temperature: -30 to 150 ° C (depending on the sealing material) (stainless steel actuator)
●Maximum temperature: -30 to 130 ° C (depending on the sealing material) (plastic actuator)
● Maximum pressure: one direction (DELTA P=100%)
Normally closed rubber 8bar, PTFE 6bar (optional)
Normally closed rubber 6bar, PTFE 4.5bar (standard)
Normally open and double acting rubber 8bar, PTFE 6bar
● Replacement of different actuators can meet higher pressure levels
●Forged valve body: 1.4404/316L/1.4435 BN2
● Casting valve body: 1.4404/316L
● Connection method: welding, clamp, flange, thread
●Operation mode: manual and pneumatic
Stainless steel vertical pneumatic actuators are mainly used in various angular stroke valves such as butterfly valves and ball valves. Various automatic control functions such as valve position feedback, valve control unit, process controller, valve intelligent positioner, etc. it can also be configured. Especially for industries with high environmental requirements such as food processing, beverages, juice, beer, pharmaceuticals and other industrial fields.
Design and features
Cylinder specifications: Φ70, 85, 114, 133, 168
Air source pressure: 4-7bar
Working temperature: -10 ° C -80 ° C
Square core with valve: 8*8, 9*9, 10*10, 11*11, 14*14mm, also available in custom sizes
Working temperature: -10 ° C -80 ° C
Output torque:
Φ70 single action = 22 N.M; double action: 45 N.M;
Φ85 single action = 35 N.M; double action: 60 N.M;
Φ114 single action = 80N.M; double action: 110 N.M;
Φ133 single action = 143N.M; double action: 180N.M;
Φ168 double action = 248N.M
Configuration: valve position feedback device, valve intelligent positioner, valve intelligent control unit, valve position sensor
Twin-screw pump has self-priming ability and can transport various complex conditions such as solid particles, gas-liquid mixture, high viscosity, low viscosity and material transportation and extraction; it not only used for material extraction and Conveying, also applicable to CIP and SIP systems, it can reduce pipeline, valve control, CIP dedicated pumps, Not only improve efficiency but also reduces costs. The pump also has the performance that other volumetric pumps do not have, such as no pulse phenomenon, no damage to particles, high pressure, speed range and large flow range.
Max flow: 110m3/h
Max Particles: 23mm
Max pressure: 20 bar
Speed range: 10-3500 R.P.M
Working temperature (Max Temperature): -40 ° C to 150 ° C
Surface treatment: Ra≤0.6μm; EP=Ra0.4μm
Material: 100% stainless steel, medium contact part 316L.
Certification: 3-A-02-11 No.1759; FDA 177.2600; CE-MD/06-42 No .705201402401-00
The C-TOP-1711 is a straight-stroke pneumatic valve control unit designed for valve process control. It is compatible with most PLC (programmable logic controller) automation systems with digital communication or bus communication (AS- I BUS). Including position feedback output, two-stage LED light display, anti-leak function, valve opening and closing control, etc., used to control all types of process valves. It can be installed on various pneumatic valves, such as pneumatic butterfly valves, ball valves, diaphragm valves, angle seat valves, globe valves, reversing valves, etc...
Control input: PNP DC 24V
Feedback Output : PNP DC 24V & 4-20mA
Power supply : DC24V ± 10%
Bus communication : AS-I-BUS
Accuracy: repeat positioning accuracy ≤ 0.5mm;
Setting: One-button auto-tuning function
Operating mode: automatic & manual
Leak prevention diagnostic function
Display: two-segment lamp color
Open: green / red
Close: red / green
Stroke range: 0-30mm
The MINI STU-10 Rotor Pump is a miniature displacement cam rotor pump for a wide range of applications for high viscosity and low viscosity material handling. The design features of the pump are small size, low noise, wide speed range, simple maintenance and economy, all-stainless steel design includes gear box and the interior is highly clean, because all-stainless steel appearance is close to no dead angle and can be washed.
Max flow: 3000 L / h
Max pressure: 12 bar
Speed range: 10-1450 R.P.M
Working temperature (Max Temperature): -40 ° C to 150 ° C
Surface treatment: Ra≤0.6μm; EP=Ra0.4μm
Material: 100% stainless steel, medium contact part 316L
Certification: 3-A-02-11 No.1759; FDA 177.2600; CE-MD/06-42 No .705201402401-00
The manifold can be assembled by containers with various functions together. It can improve working efficiency of system and control the whole production process. The manifold can choose any flexible hose pipe and jet deviator to change the flexure automatically. The kind of automatic operation is safe, flexible and effective. One set of manifold can served to multi pipelines. Meanwhile other containers are filled in or empty, operator can clean up any one of them. The liquid won't be polluted.
Size：1.5"-DN40 to 4"-DN100
Manifold：from 4 up to 48 valves
Temperature：130℃
Pressure：10bar
Air supply：5-7bar
Control Systems
◆With a simple C-TOP on every pneumatic actuator (solenoids and sensors)
◆With a C-TOP of AS-I field bus
◆Without C-TOP, solenoids are installed in the control panel and sensors on the pneumatic actuator
◆PLC control
◆The states of the valves can be displayed on the control panel
PMZX series is a multifunctional material-liquid mixing pump with functions of mixing, shearing, emulsifying, homogenizing, differentiating, refining, crushing and material quality improvement. Compare with traditional production process, this pump is simpler, more convenient and economical, it can improve the production efficiency & improves the quality of the materials to be treated. Mainly used in food, beverages, dairy products, additives, personal care, biopharmaceuticals, thickeners, industrial applications.
The maximum processing capacity of powder: 9000KG/h
Maximum processing of thickeners: 3000KG/h (depending on material viscosity and concentration)
Maximum temperature: 130 ° C
Material: 304 /316L, 1.4301/1.4404, ASME BPE 316L, 1.4435 BN2 Fe≤0.5%
Surface treatment: ≤ Ra0.8μm, ≤ Ra0.6μm, ≤ Ra0.4μm
Machine seal: single machine seal and double machine seal
Inlet/outlet connections: Thread, clamp, flange, sterile flange
Certification: 3-A-02-10 (N.O.1579); MD/06/42-EC (N.O.70521616101-00); FDA 177.2600; USP CLASS-II; EG/VO1935/2004;
RX series flexible pump is a positive displacement pump with excellent self-priming performance, and its self-priming capacity can reach 5 meters. The efficiency of pumping viscous products almost reaches the effect of pumping water.
The sampling valve has a dead angle-free design and the end face connected to the container does not have a dead zone phenomenon.
◎ It is mainly used for sample collection of materials in tank equipment or pipelines. It can also be installed at the lowest point of tank equipment or pipelines to drain residual liquid.
◎Working principle: the handwheel rotates the valve stem clockwise together with the sealing ring. At this time, the valve is opened for sampling. The handwheel rotates the valve stem counterclockwise together with the sealing ring. The valve is closed.
◎Applicable temperature: -10 ° C to 130 ° C
◎ valve body material: AISI 304 AISI 316L
◎ Sealing material: PTFE
◎Connection method: clamp type, thread type, welding type, nut type
The three way globe valve is mainly used in flow regulation control and reversing valves. This valve is in contact with the medium only in stainless steel and PTFE, with a maximum temperature of 180 ° C and a pressure resistance of up to 20 bar. It can also be used in a vacuum environment. The valve body is designed according to the dead angle, the surface roughness can reach Ra0.4μm, the valve core seal adopts the embedded design, so it can be used in a wide range of industries, such as pharmaceutical, food and beverage, brewing, chemical and other industrial fields. .
Design Features
◆Specifications: 1/2"-4", DN10-DN80
◆Material: CF8/304, CF8M/316
◆Connection standard: thread, clamp, flange, BSP, BSP, NPT, DIN
◆Working pressure: 8bar (standard) 10bar (optional)
◆Working temperature: 120 ° C (standard) 180 ° C (optional)
equipment systems. The butterfly valve has the characteristics that standard butterfly valve does not have, such as ultra-small torque, seal opening and closing does not produce excessive friction, long life, No seal powder shedding, ultra-short valve body, and adjustable pressure. The valve does not require professional tools to be disassembled, maintained, cleaned, safe, reliable, low cost, simple to operate, and can be interchanged manually, pneumatically, or electrically.
Specifications: 4''-10'', DN100-DN250
Connection method: clamp, welding, flange, bottom flange, DIN 3A INCH
Material: 316L/1.4404/1.4435
Seal: White SILCON (recommended) Gray FKM (selection)
Execution mode: manual, pneumatic, electric interchangeable
Surface treatment: Ra 0.6μm (recommended); Ra 0.4μm (selection)
External surface: matt (recommended) bright blasting electropolishing
Applicable: vacuum, high temperature 130 ° C, CIP cleaning, SIP sterilization, etc.
Lobe pump is available in a variety of configurations, TU series is standard configuration . STU series is all stainless steel. It is a positive displacement cam rotor pump designed according to the strict sanitary requirements of the US 3A-02-11. It is very suitable for transportation of various highly viscous and low-viscous materials such as food processing, beverages, juices, dairy products, cosmetics, the pharmaceutical industry can be carried out with solid particulate materials, also can be applied to CIP and SIP systems. The pump has features not found in other volumetric pumps, such as low pulse, high pressure, rotary two-way reversible and flexible functional combinations.
Maximum flow Max.flow: 90m3 / h / 395 GPM
Maximum pressure Max.pressure: 15bar/220 Psi
Maximum temperature Max.Temperature: 150°C/302°F
Maximum speed Max.rev: 750 rpm
Material: 316L, 1.4404, ASME BPE 316L, 1.4435 NB2 Fe ≤ 0.5%
Surface treatment: ≤ Ra0.8μm, ≤ Ra0.6μm, ≤ Ra0.4μm
Certification : 3-A-02-11 No.1759; FDA 177.2600; CE-MD/06-42 No .705201402401-00
DJ-FDT butterfly valve is mainly designed for powder, granule, capsule and other container equipment systems. The butterfly valve has the characteristics that standard butterfly valve does not have, such as ultra-small torque, seal open/close does not produce excessive friction, long life, No seal powder shedding, ultra-short valve body and adjustable pressure. The valve does not require professional tools to be disassembled, maintained, cleaned, safe, reliable, low cost, simple to operate and can be interchanged manually, pneumatically or electrically.
Specifications: 4''-10'', DN100-DN250
Connection method: clamp, weld, flange, bottom flange, DIN 3A INCH
Material: 316L/1.4404/1.4435
Seal: White SILICON (recommended) Gray FKM (selection)
Execution mode: manual, pneumatic, electric interchangeable
Surface treatment: Ra 0.6μm (recommended); Ra 0.4μm (selection)
External surface: matte (recommended) bright blasting electropolishing
Applicable: vacuum, high temperature 130 ° C, CIP cleaning, SIP sterilization, etc.
F-TOP-1671 is a rotary angular stroke pneumatic valve position feedback device designed for valve process position feedback. It is compatibled with most PLC (programmable logic controller) automation systems with digital communication or bus communication. (AS-I BUS). Including position feedback output, three-segment LED display, anti-leakage function, etc., used to control all types of process valves. It can be mounted on a variety of pneumatic valves, such as pneumatic butterfly valves, ball valves, globe valves and other rotary stroke valves.....
Feedback Output : PNP DC 24V & 4-20mA
Power supply : DC24V ± 10%
Bus communication : AS-I-BUS
Accuracy: Repeat positioning accuracy ≤ 0.2%;
Setting: One-button auto-tuning function
Leak prevention diagnostic function
Display: three-segment lamp color
Open: green / red
Close: red / green
Middle position: yellow (used for mixing proof valve )
Stroke angle: 0-180°
C-TOP-1881 is a straight-stroke pneumatic valve control unit designed for valve process control. It is compatibled with most PLC (programmable logic controller) automation systems with digital communication or bus communication (AS- I BUS). Including position feedback output, two-stage LED light display, anti-leak function, valve opening and closing control, etc., used to control all types of process valves. It can be mounted on a variety of pneumatic valves, such as pneumatic butterfly valves, ball valves, diaphragm valves, angle seat valves, globe valves, reversing valves, etc.…..
Control input: PNP DC 24V
Feedback Output : PNP DC 24V
Power supply : DC24V ± 10%
Bus communication : AS-I-BUS
Accuracy: Repeat positioning accuracy ≤ 0.2%;
Setting: One-button auto-tuning function
Operating mode: automatic & manual
Leak prevention diagnostic function
Display: two-segment lamp color
Open: green / red
Close: red / green
Travel range: 0-60mm/0-30mm
The PM series is a multifunctional material-liquid mixing pump with functions of mixing, shearing, emulsifying, homogenizing, differentiating, refining, crushing and material improvement. Compare with traditional production process, this pump is simpler, more convenient and economical, it can improve the production efficiency& improve the quality of the materials to be treated. Mainly used in food, beverages, dairy products, additives, personal care, biopharmaceuticals, thickeners, industrial applications.
The maximum processing capacity of powder: 9000KG/h
Maximum processing of thickeners: 3000KG/h (depending on material viscosity and concentration)
Maximum temperature: 130 ° C
Material: 304 /316L, 1.431/1.4404, ASME BPE 316L, 1.4435 NB2 Fe≤0.5%
Surface treatment : ≤ Ra0.8μm, ≤ Ra0.6μm, ≤ Ra0.4μm
Machine seal: single machine seal and double machine seal
Inlet/outlet connections: Thread, clamp, flange, sterile flange
Certification: 3-A-02-10 (N.O.1579); MD/06/42-EC (N.O.70521616101-00); FDA 177.2600; USP CLASS-II; EG/VO1935/2004;
The JZ3 series is an in-line continuous production emulsified homogenizing pump consisting of stator and rotor. The treated material will be dispersed, sheared, refined, crushed and emulsified step by step through total 12 layers of rotor and stator. Mixing, homogenizing, etc. Compared with the traditional production process, the pump is simpler, more convenient and optimized, it improve the production efficiency and quality of the material to be treated. Mainly used in various industrial fields such as food, beverage, pharmaceutical, health care, fine chemicals, coatings, pesticides, daily washing, photo paper, etc.
Maximum flow rate Max Flow rate: 50m3/h
Maximum power Max power :55KW
Maximum temperature Max temperature: -20 ° C to 140 ° C
Material refinement Media refinement: ≤ 100 GRIT (≈ 200μm) ≤100 mesh (approx. 200μm)
Material: 304 /316L, 1.431/1.4404, ASME BPE 316L, 1.4435 NB2 Fe≤0.5%
Surface treatment: ≤ Ra0.8μm, ≤ Ra0.6μm, ≤ Ra0.4μm
Machine seal: single seal and double seal
Inlet/Outlet Connection: Thread, Clamp, Flange, Aseptic Flange
Certification: 3-A-02-10 (N.O.1579); MD/06/42-EC (N.O.70521616101-00); FDA 177.2600; USP CLASS-II; EG/VO1935/2004;
The JZ1 series is an in-line continuous production emulsified homogenizing pump consisting of stator and rotor. The treated material will be dispersed, sheared, refined, crushed, emulsified and mixed through 6-10 layers of rotor and stator. , homogenization, etc. Compared with the traditional production process, the pump is simpler, more convenient and more optimized, it improves the production efficiency and quality of the material to be treated. Mainly used in food, beverage, pharmaceutical, health care, fine chemicals, coatings, pesticides, daily washing, paper and other industrial fields.
Maximum flow rate Max Flow rate: 50m3/h
Maximum power Max power :55KW
Maximum temperature Max temperature: -20 ° C to 140 ° C
Material refinement Media refinement: ≤ 60 GRIT (≈ 300μm) ≤60 mesh (about 300μm)
Material: 304 /316L, 1.431/1.4404, ASME BPE 316L, 1.4435 NB2 Fe≤0.5%
Surface treatment: ≤ Ra0.8μm, ≤ Ra0.6μm, ≤ Ra0.4μm
Machine seal: single seal and double seal
Inlet/Outlet Connection: Thread, Clamp, Flange, Aseptic Flange
Certification: 3-A-02-10 (N.O.1579); MD/06/42-EC (N.O.70521616101-00); FDA 177.2600; USP CLASS-II; EG/VO1935/2004;
